Q Lite 11kW

Q Lite 11kW

18291.08

In stock

• Our home model offers an 11kW option. It comes with a cable and serves as an ideal, cost-effective solution for personal use.

• It enables charging with a maximum power of 11kW.

• The socket type used in the product is Type-2.

• Designed with a Plug-and-Play approach, charging begins automatically when you connect the plug to the vehicle.

• It is compatible with all electric and plug-in hybrid vehicles conforming to the EN61851 standard approved by the European Union.



  • Features
Nominal Input
Connection 3 Phase + N + PE
Voltage (V) 400 VAC ±% 10
Frequency (Hz) 50/60 Hz
Nominal Output
Voltage(V) 400 VAC ±% 10
Current(A) 16A
Power (kW) 11kW
Hardware
Wi-Fi, 3G, 4G Optional
Ethernet 10/100Mbit/s
RF-ID No
LCD Screen No
Energy Analzyer Optional
RS-485 Yes
RS-232 No
Emergency Stop Yes
Temperature Detection Yes
General Features
Material Plastic
Mounting Method Wall
Socket/Cable Type Type-2 Socket
Cable Length (m) 5m (Opsiyonel 8m)
Operating Temperature (°C) -30 ~ +70°C
Operating Humidity (%) %5-98 Relative Humidity
IP Rating IP54
Dimensions (mm) W:245 D:1515 H:290
Heigth(kg) 7,4 kg
Protection and Warranty
Electrical Protection 30mA AC (6mA DC Opt.)
Safety Standart
Warranty Period (Year) 2 Years
